178
Setting the Conditions for Communications with the Host by Using the Memory Switches
Section 6-7
S To quit the communications speed setting screen without setting the commu-
nications speed, press the “Abort” touch switch. The NT31/NT31C returns to the
memory switch setting screen (4/4) and the previous communications speed re-
mains in effect.
On completion of communications speed setting, the NT31/NT31C returns to the
memory switch setting screen (4/4).
To set other memory switches, select the relevant screen using the [ ] (next
screen) or [ ] (previous screen) touch switch, then make the setting.
S To confirm the settings and quit the memory switch setting screen, press the
“Quit” touch switch. The settings made last will be set and the NT31/NT31C will
return to the “MAINTENANCE MODE MENU” screen.
S To quit the memory switch setting screen without confirming the settings, press
the “Abort” touch switch. The NT31/NT31C will return to the “MAINTENANCE
MODE MENU” screen with the previous settings still in effect.
6-7-3 Setting the NT Link (1:1) Method
Set the communication conditions for the NT link (1:1) method at serial port A or
serial port B by following the operation from the System Menu shown below.
Select “Maintenance Mode”.
Select “Memory Switch”.
Display the fourth memory switch screen by
pressing the [ ] (next screen) or [ ] (previous
screen) touch switch.
To Next Page
