Omron NT31 User Manual

134
Connecting to the Host’s RS-422A/485 Port
Section 5-2
 Wiring when connecting CPM1, SRM1
Applicable units:
CPM1-10CDR- CPM1-20CDR-
CPM1-30CDR-
CPM1A-10CD- CPM1A-20CD-
CPM1A-30CD- CPM1A-40CD-
SRM1-C02-V1
1
14
13 25
NT31/NT31C side
Shielding wire
(25-pin type)
Abbreviation
FG
−
SD
RD
RS
CS
−
SG
−
TRM
RDB (+)
SDB (+)
−
−
−
SDA (−)
RDA (−)
−
−
RSB (+)
RSA (−)
−
Pin number
Connector
hood
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
−
23
24
25
RS-232C/
422A/485
connector
PC side
RS-422A
terminal
block
Abbreviation
FG
SG
SDB (+)
SDA (−)
RDB (+)
RDA (−)
(9-pin type)
FG
SG
SDB
SDA
RDB
RDA
In order to avoid an FG ground loop, do not connect the functional ground of the
NT31/NT31C to the shielding of the RS-422A cable.
