358
Numeral Display
Section 7-8
[Common Attributes]
The relationship between the properties of a numeral display and the displayed
numeric value is indicated below.
S Properties
General
Position Coordinates of the top left corner of the field in which the numeric
value is displayed.
Font Type Font for the characters
Standard/Half Height/Double Width
Scale Scale at which the numeric value is displayed (“Enlarged
display”, page 359).
11 (Equal), 12 (High), 21 (Wide), 22, 33, 44,
88
Smoothing Whether or not smoothing is used for numerals with a scale of 22
or larger (“Smoothing”, page 359).
Check mark (smoothing executed)/
No check mark (smoothing not executed)
Attribute Display mode for the numerals (“Display attributes and drawing
result”, page 359).
Standard/Flash/Inverse Flash
Color
Foreground Display color of the numerals (colors other than black and white
featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the numerals (colors other than black and
white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Settings
Reference
Indirect
Reference
Method for referencing the numeral memory table (“Direct
reference and indirect reference”, page 360)
Check mark (Indirect Reference)/
No check mark (Direct Reference)
Table Entry Numeral memory table number referenced for display (“Direct
reference and indirect reference”, page 360)
4-digit BCD value
 When “Direct Reference” is specified:
Table number of the numeral memory table in which the
numeric value to be displayed is stored
 When “Indirect Reference” is specified:
Table number of the numeral memory table in which the
number of the numeral memory table whose contents are to
be displayed is stored.
Display Type Display format for the numeric value (“Stored data and
displayed numeric value”, page 361)
Decimal/Hexadecimal
Format (“Number of digits displayed”, page 360)
Integer Number of digits in the integer part of the numeric value
Decimal Number of digits in the decimal fraction of the numeric value
