434
Inputting Character Strings
Section 7-13
[Restrictions]
S A maximum combined total of 256 of the following elements can be registered
for one screen. (Same for window screen) Even in the case of an overlapping
screen with eight child screens, it is only possible to register character string in-
put fields on one of the child screens.
Character string input field
There is no restriction on the number of input fields that can be registered for one
screen data file: any number can be registered as long as the data file capacityis
not exceeded. However, if a large number ofelements areregistered, checkthat
the restrictions on element display are complied with by referring to “Display Re-
strictions” (page 644).
S It is not possibleto set character string input from more than one character string
input field on the same screen to one character string memory table.
S The following numbers of characters can be displayed in one character string
input field, depending on the scale.
1
×
1 (Equal): Up to 40 characters
1
×
2 (High): Up to 40 characters
2
×
1 (Wide): Up to 20 characters
2
×
2: Up to 20 characters
3
×
3: Up to 13 characters
4
×
4: Up to 10 characters
8
×
8: Up to 5 characters
S The characters that can be displayed are alphanumerics, symbols and Marks.
Marks are displayed at thestandard height even if “Half Height” is set as the Font
Type. Therefore, if normal alphanumerics and symbols are displayed after dis-
playing a mark, part of the mark will remain displayed, as shown in the figure
below.
S If “Half Height” is set for “Font Type”, and a character string is written after dis-
playing Marks, a part of the Marks will remain displayed, as shown below.
ABCDE
abcdefghij
In this case, create blank characters as marks, write these marks, and then write
the alphanumeric and symbol character string over them.
S It is not possible to register multiple input fields which refer to the same string
table on the same screen.
To Next Page
