460
Inputting Character Strings
Section 7-15
Printing Display History and Alarm History Record Data
The display history and alarm history recorded in the NT31/NT31C can be printed
out by calling the “display history” and “alarm history” display screens from the
System Menu.
To print when the NT31/NT31C is running, display a display history dedicated
screen, or a screen for which an alarm history is registered, then print it using the
screen print function.
Switch between screensby pressinga touch switchallocated the screenswitching
function, or by writing the screen number to the “screen switch setting” word in the
PT status control area. To print a screen, either press a touch switch allocated the
screen print function or set the “screen printing” bit in the PT status control bits to
“ON”.
The display history dedicated screens are:
Occurrence history screen: 9001
Frequency history screen: 9002
S Printing example
- Display history
Occurrence order
No. Scrn YY/MM/DD HH:MM Comment 1/1
1 1 98/02/23 08:45 menu screen
2 4 98/02/23 08:46 alarm screen
3 3 98/02/23 08:47 setting screen
4 4 98/02/23 08:47 alarm screen
5 1 98/02/23 08:48 menu screen
6 4 98/02/23 08:50 alarm screen
7 3 98/02/23 08:51 setting screen
8 1 98/02/23 08:55 menu screen
9 4 98/02/23 09:06 alarm screen
10 1 98/02/23 09:07 menu screen
11 3 98/02/23 09:07 setting screen
12 4 98/02/23 10:50 alarm screen
13 1 98/02/23 10:51 menu screen
14 3 98/02/23 10:52 setting screen
Frequency order
No. Scrn Cnt. Comment 1/1
1 1 14 menu screen
2 4 10 alarm screen
3 3 8 setting screen
To Next Page
