Commands/Responses
Section 9-3
9-3-4 Bit memory table read command (Sent from host to PT)
Command
[Format]
1B 52
[ESC]
[CR]
R
0D
42
B
mt1t2 t4
(l1) (l2) (s1) (s2)
t3
** ** ** ** **
** ** ** **
m : Check sum present/absent (1 BCD digit)
0 : Absent
1 : Present
8 : Absent (1 table read)
9 : Present (1 table read)
t
1
to t
4
: First bit memory table number read (4 BCD digits)
0000 to 0999
l
1
,l
2
: Number of read tables (2 BCD digits)
00 :100
01 to 99 :1 to 99
When m is 8 or 9, omit this setting.
s
1
,s
2
: Check sum (2 hexadecimal digits)
When m is 0 or 8, omit this setting.
Reference:
The maximum number which can be specified for “first bit memory table read” de-
pends on the setting for numbers of bit memory table entries (256/1000) made at
the Support Tool.
Response
[Format]
1B 52
[ESC] R
t3 t4
42
Bt1
2C
d11
,
t2
dn1 dn2
d12 d13 d14
0D
dn3 dn4
s1
s2 [CR]
l1 l2
** **** ** ** ** ** ** ** ** ** **** **
** ** **** ****
t
1
to t
4
: First bit memory number table read (4 BCD digits)
0000 to 0999
l
1
,l
2
: Number of read tables (2 BCD digits)
00 :100 tables
01 to 99 :1 to 99 tables
