Compatibility with Screen Data of Other PT Models
APPENDIX I
Differences between the NT31/NT31C without “V1”
and the NT31/NT31C with “V1”
Item NT31/NT31C (without V1) NT31/NT31C (with V1)
Drowing
order of
objects
Display Object Types
Image/library lamp
Alarm list/history frame
Temporary input
String input
Thumbwheel
Numeral input
Trend graph
Broken line graph
Bar graph
Numeral display
String display
Fixed display
Lamp
Touch switch
Image/library
Screen background
Top
Bottom
Display Object Types
Image/library lamp
Alarm list/history frame
Temporary input
String input
Thumbwheel
Numeral input
Trend graph
Broken line graph
Analogue meter
Bar graph
Numeral display
String display
Fixed display
Lamp
Touch switch
Image/library
Screen background
Top
Bottom
PT status
notify area
PT status notify bits
00 0
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Word m
Word m+1
Word
Numeral/character string memory table number
(BCD or hexadecimal 4 digits)
PT status notify bits
000
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Word m
Word m+1
Word
Numeral/character string memory table number
(BCD or hexadecimal 4 digits)
PT status notify bits
Word Notified Information 1 (ON) 0 (OFF)
15 PT operation status Run Stop
14 Not used Always “0”
13 Battery Low Normal
12 Screen switch strobe ON OFF
11 Numeral setting strobe ON OFF
10
Character string setting strobe ON OFF
9 Not used Always “0”
8 Not used Always “0”
7 Printer operating status Printing Stopped
6 Backlight status OFF Lit/flashing
PT status notify bits
Word Notified Information 1 (ON) 0 (OFF)
15 PT operation status Run Stop
14 Not used Always “0”
13 Battery Low Normal
12 Screen switch strobe ON OFF
11 Numeral setting strobe ON OFF
10
Character string setting strobe ON OFF
9 Not used Always “0”
8 Not used Always “0”
7 Printer operating status Printing Stopped
6 Backlight status OFF Lit/flashing
5 Global window open status Open Close
4 Local window “1” open status Open Close
3 Local window “2” open status Open Close
