67
Connecting to the RS-232C Port at the Host
Section 4-1
4-1-1 Host Types and Settings
The types of host that can be connected to a PT by using the RS-232C ports of
both units, and the settings to be made at the host, are described here.
When Using the Host Link Method
S Compatible host units
Some models and series of OMRON PCs have the host link function built in.
S In the CS1 series, the host link method can be used by installing a serial commu-
nication board. In addition, some C200HX/HG/HE (–Z) have an integral CPU
that can be connected in the host link method by installing a communication
board.
Check the model and series of the PC, the type of installed serial communication
board, the serial communication unit, and the host link unit at the connection end
before making a connection.
The host units that can be connected to the NT31/NT31C by the host link meth-
od using the RS-232C ports of both units are indicated in the table below.
PLC Series
Units with Built-in Host Link
Function
CPUs Connectable with Host
Link Units or Expansion Com-
munication Board
Host Link Unit/
Commu
nication Board
Connectable to
CS1 Series
CS1G-CPU42/43/44/45-E
CS1H-CPU63/64/65/66/67–E
CS1G-CPU42/43/44/45-E
CS1H-CPU63/64/65/66/67-E
CS1W-SCB41-E
CS1G
CS1H
C200H-CPU01/02/03/11/
21/22/23/31-E
C1000H–CPU01-EV1
C2000H–CPU01–EV1
C120–LK201-EV1
C200H
C1000H
C2000H
C200H-CPU01/2/03/11/
21/22/23/31-E
C200HS-CPU01/03/21/23/
31/33-E
C200HE-CPU11/32/42–E
C200HE-CPU11/32/42-ZE
C200HG-CPU33/43/53/63-E
C200HG-CPU33/43/53/63–ZE
C200HX-CPU34/44/54/64-E
C200HX–CPU34/44/54/64
65/85-ZE
C200H-LK201-EV1
C200H
C200HS
C200HE
C200HE-Z
C200HG
C200HG-Z
C200HX
C200HX–Z
C200HS-CPU21/23/31/33 C200HS
C Series
C200HE-CPU42
C20HE-CPU42-Z
C200HE-CPU32/42-E
C200HE-CPU32/42-ZE
C200HW-COM02/04/
05/06-EV1
C200HE
C200HE-Z
C Series
C200HG-CPU43/63
C200HG-CPU43/63-Z
C200HG–CPU33/43/53/63-E
C200HG–CPU33/43/53/63–ZE
C200HG
C200HG-Z
C200HX-CPU44/64
C200HX-CPU44/64/65/85-Z
C200HX-CPU34/44/54/64–E
C200HX-CPU34/44/54/64/
65/85-ZE
C200HX
C200HX-Z
C1000H-CPU01-EV1
C2000H-CPU01-EV1
C500-LK201-EV1
C1000H
C2000H
C1000H-CPU01-EV1
C1000HF-CPUA1-EV1
C2000H-CPU01-EV1
C500-LK203
C1000H (F)
C2000H
CPM1–10/20/30CDR-
+CPM1-CIF01
CPM1
CPM1A-10/20/30/40CD
+CPM1-CIF01
CQM1-CPU21
CQM1-CPU41/42/43/44-V1
CQM1
