2-22
2-4 External and Mounting Dimensions
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
2
Models and External Dimensions
Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
40
7
180
170
150
5.2
R26
7
φ5.2
2.5
132
19.5
2.5
7
φ5.2
70
170
(42)*
(158)*
* Rectangular hole dimensions are reference values.
Rectangular
hole
