Omron OMNUC G5 Series

2-28
2-4 External and Mounting Dimensions
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
2
Models and External Dimensions
3-phase 400 VAC: R88D-KN06F-ECT-R/-KN10F-ECT-R (600 W to 1.0 kW)
3-phase 400 VAC: R88D-KN15F-ECT-R (1.5 kW)
Wall Mounting
External dimensions Mounting dimensions
Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
92
150
172
4
150 140
70
14.5
70
φ5.2
92
92
60
40
10
φ5.2 φ5.2
170 180 150
5.2 5.2
10
40
R2.6
172
70
4
2.5
19.5
2.5
40
18
6
(94)*
170
(158)*
φ5.2
* Rectangular hole dimensions are reference values.
Rectangular
hole
