2 Models and External Dimensions
2 - 4
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-2 How to Read Model Numbers
This section describes how to read and understand the model numbers of Servo Drives, Servomotors,
and Decelerators.
The Servo Drive model number tells the Servo Drive type, applicable Servomotor, power supply volt-
age, etc.
2-2-1 Servo Drive
01
02
04
06
08
10
15
20
30
55
75
150
R88D-1SN01H-ECT
100 W
200 W
400 W
600 W
750 W
1 kW
1.5 kW
2 kW
3 kW
5.5 kW
7.5 kW
15 kW
N
L
H
F
100 VAC
200 VAC
400 VAC
ECT
Communications type
Applicable Servomotor rated output
Power supply voltage
Servo Drive type
1S-series
Servo Drive
Communications type
EtherCAT communications
