4 System Design

4-44

G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type

Model

Rated

current

Dimensions [mm]

A B C D1 D2

Core

thickness

E F

RJ8035 35A 170 150 23 80 53 24 R3.5 7

RJ8095 95A 200 180 34 130 107 35 R3.5 7

51.5

φ25.5

φ57.2

φD2

φD1

φ102

17.5

φ5.1

3.0

6.5

34.0

ESD-R-47B

3039

ZCAT3035-1330

RJ8035/RJ8095

T400-61D
