Omron R88D-KN series User Manual

12-5
12 Troubleshooting and Maintenance
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
12-2 Warnings
12
12-2-2 Warning List
There are two types of warnings: general warnings and warnings related to EtherCAT communications.
*1 The check mark symbol () in the above table means that you can switch between Latch and Non-latch modes
in the Warning Hold Selection (3759 hex). Life Expectancy Warning is fixed to Latch mode only.
*2
Set the Warning Output Selection 1 (3440 hex) to the warning type to output to Warning Output 1 (WARN1),
and set the Warning Output Selection 2 (3441 hex) to the warning type to output to the Warning Output 2
(WARN2). If you set these objects to 0, all warning types are output.
*3 Detection of general warnings can be masked with the Warning Mask Setting (3638 hex) and detection of
EtherCAT communications-related warnings can be masked with the Communications Control (3800 hex).
When the bit is set to 1, the warning detection is masked.
Precautions for Correct UsePrecautions for Correct Use
• Do not use any settings for Error Output Selection 1 (3440 hex) and Error Output Selection 2
(3441 hex) other than those given in the above table.
• You can clear these warnings by executing the error rest command. The command does clear
the warning even if the cause of the warning is not removed, but the same warning will occur
again.
12-2-2 Warning List
General Warnings
Warning
number
Warning name Warning condition
Warning
Hold
Selection
(3759 hex)
*1
Warning
Output
Selection
(3440 hex,
3441 hex)
* 2
Warning
Mask
Setting
(3638 hex)
* 3
A0 hex Overload Warning The load ratio is 85% or more of the
protection level.

1Bit 7
A1 hex Excessive
Regeneration
Warning
The regeneration load ratio is 85%
or more of the level.
 2Bit 5
A2 hex  Not used (Do not use.)
A3 hex Fan Warning The fan stop state continues for 1
second.
 4Bit 6
A4 hex  Not used (Do not use.)
A5 hex  Not used (Do not use.)
A6 hex Vibration Detection
Warning
Vibrating is detected.  7Bit 9
A7 hex Life Expectancy
Warning
Life Expectancy Warning Fixed to
latch mode
8Bit 2
A8 hex External Encoder
Error Warning
The external encoder detects a
warning.
 9Bit 8
A9 hex External
Encoder
Communications
Warning
The external encoder has
communications errors in series
more than the specified value.
 10 Bit 10
