2-7
2 Models and External Dimensions
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
2-3 Model Tables
2
2-3-2 Cable and Peripheral Device Model Tables
External Regeneration Resistors
Specifications Model
Regeneration process capacity: 20 W, 50 (with 150C thermal sensor) R88A-RR08050S
Regeneration process capacity: 20 W, 100 (with 150C thermal sensor) R88A-RR080100S
Regeneration process capacity: 70 W, 47 (with 150C thermal sensor) R88A-RR22047S1
Regeneration process capacity: 70 W, 47 (with 170C thermal sensor) R88A-RR22047S
Regeneration process capacity: 180 W, 20 (with 200C thermal sensor) R88A-RR50020S
Reactor
Applicable Servo Drives Model Reactor type
R88D-KN01H-ECT-L (For single-phase input) 3G3AX-DL2002 DC reactor
R88D-KN01L-ECT-L/-KN02H-ECT-L (For single-phase input) 3G3AX-DL2004
R88D-KN02L-ECT-L/-KN04H-ECT-L (For single-phase input) 3G3AX-DL2007
R88D-KN04L-ECT-L/-KN08H-ECT-L/-KN10H-ECT-L
(For single-phase input)
3G3AX-DL2015
R88D-KN15H-ECT-L (For single-phase input) 3G3AX-DL2022
R88D-KN01H-ECT-L/-KN02H-ECT-L/-KN04H-ECT-L/
-KN08H-ECT-L/-KN10H-ECT-L/-KN15H-ECT-L
(For 3-phase input)
3G3AX-AL2025 AC reactor
R88D-KN20H-ECT-L/-KN30H-ECT-L 3G3AX-AL2055
R88D-KN50H-ECT-L 3G3AX-AL2110
R88D-KN75H-ECT-L/-KN150H-ECT-L 3G3AX-AL2220
R88D-KN06F-ECT-L/-KN10F-ECT-L/-KN15F-ECT-L 3G3AX-AL4025
R88D-KN20F-ECT-L/-KN30F-ECT-L 3G3AX-AL4055
R88D-KN50F-ECT-L 3G3AX-AL4110
R88D-KN75F-ECT-L/-KN150F-ECT-L 3G3AX-AL4220
Mounting Brackets (L-brackets for Rack Mounting)
Applicable Servo Drives Model
R88D-KN01L-ECT-L/-KN01H-ECT-L/-KN02H-ECT-L R88A-TK01K
R88D-KN02L-ECT-L/-KN04H-ECT-L R88A-TK02K
R88D-KN04L-ECT-L/-KN08H-ECT-L R88A-TK03K
R88D-KN10H-ECT-L/-KN15H-ECT-L/-KN06F-ECT-L/-KN10F-ECT-L/-KN15F-ECT-L R88A-TK04K
To Next Page
