Omron R88D-KN series

A-143
Appendicies
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
A-3 Sysmac Error Status Codes
App
A-3-2 Error Description
Event name Magnetic Pole Position Estimation Error 3 Event code 38550000 hex
Meaning Magnetic pole position restoration was not completed successfully.
Source EtherCAT Master Function Module Source details Slave Detection
timing
When the magnetic
pole position
restoration method
is selected.
Error attributes Level Minor fault Recovery Error reset (after
cycling slave
power)
Log category System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Remedy Prevention
The Magnetic Pole Detection Method
(3920 hex) object was set to 3
(Magnetic pole position restoration
method), although the Magnetic Pole
Position Estimation had never been
executed.
Set the Magnetic Pole Detection
Method (3920 hex) to 2 (Magnetic
pole position estimation method) and
execute the Magnetic Pole Position
Estimation once.
Then, set the Magnetic Pole
Detection Method (3920 hex) to 3
(Magnetic pole position restoration
method).
Before setting the Magnetic Pole
Detection Method (3920 hex) object
to 3 (Magnetic pole position
restoration method), once set the
object to 2 (Magnetic pole position
estimation method) and execute the
Magnetic Pole Position Estimation.
The Magnetic Pole Detection Method
(3920 hex) was set to 3 (Magnetic
pole position restoration method)
when a non-absolute type external
encoder was used.
Change the external encoder to an
absolute type.
Before setting the Magnetic Pole
Detection Method (3920 hex) object
to 3 (Magnetic pole position
restoration method), make sure that
your external encoder is an absolute
type.
Attached
information
None
Precautions/
Remarks
“61” is displayed on the Servo Drive front panel and F261 is given as the AlarmCode (4001 hex).
