Omron R88D-KN series

2-23
2 Models and External Dimensions
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
2-4 External and Mounting Dimensions
2
2-4-1 Servo Drive Dimensions
 Wall Mounting
External dimensions
Mounting dimensions
3-phase 400 VAC: R88D-KN150F-ECT-L (15 kW)
70
R3.5 R3.5
Ø7
Ø7
4
231
30.5
435
7.5
450
30.5
231
261
271
450
435
261
200 30.5
7.5
4-M6
