4 Check and start operation
4-4 UPS operation mode settings
S8BA-24D24D□□□LF
66
(C)
(C)
(B)
(B)
(B)
(
B)
(B)
(B)
(B)
(B)
(B)
(C)
(C)
(C)
(C)
(B)
(B)
(B)
(C)
(C)
(B)
(B)
(B)
Display
current
setting
(next page)
Display
current
setting
Display
current
setting
Display
current
setting
(previous page)
Battery life counter
setting
Standard voltage
sensitivity (default)
High voltage sensitivity
Stop when circuit is
closed (default)
Stop when circuit is open
Enable cold start
Enable battery life
counter (default)
Disable battery life
counter
Disable cold start
(default)
Low voltage sensitivity
Logic of Remote
ON/OFF signal setting
Input sensitivity
setting
Cold start setting
Operation (A): pressing the “Beep Stop/Test” switch and turn on the “Power” switch.
Operation (B): pressing the “Beep Stop/Test” switch below 1 second and then release it.
Operation (C): pressing the “Beep Stop/Test” switch 1 second or more and then release it.
Operation (D): turning off the “Power” switch.
