5 Maintenance and inspection
5-2 Replacing the battery
S8BA-24D24D□□□LF
78
2. Push down the battery cover's clamp with a 5 mm or less blade screwdriver.
Push down also the clamp at the opposite side in the same way and remove the battery
cover by pulling it toward you.
Battery cover's clamp
Battery cover
Battery cover's clamp
