5-2 Replacing the battery
5 Maintenance and inspection
S8BA-24D24D□□□LF
79
5
3. Pull up the lever of the battery control board toward you.
Lever
4. Insert a tool such as a screwdriver into the hole (the clamp that keeps the battery in
place) located on the top of the main body and push the battery out a little toward you.
Insert a tool such as a screwdriver
into the hole and push the battery
out toward you
Hole
