Omron SMARTSTEP 2 R88M-G Series - External Regeneration Resistor Dimensions

2-33
2-2 External and Mounted Dimensions
2
Standard Models and Dimensions
External Regeneration Resistor Dimensions
 External Regeneration Resistor
R88A-RR08050S/R88A-RR080100S
R88A-RR22047S1
20
t1.2 104
122
130
43.5
28
4.2
6
1.5 dia. (0.3 mm
2
)
(0.75 mm
2
)
3 dia.
Thermal switch output
500
20
t1.2 200
220
230
62 48
4.2
6
Thermal switch output
500
1.5 dia. (0.3 mm
2
)
(0.75 mm
2
)
3 dia.
