5-5 Electronic Gear
5
Operating Functions
Calculation Examples
To operate with 2,000 pulses/rotation:
To operate with 1,000 pulses/rotation:
Conversely, to increase the resolution per rotation and operate with 40,000 pulses/rotation:
The setting ranges for Pn46, Pn47, and Pn4B, however, will be 1 to 10,000, so reduction to one
of the following is required.
Make reductions so that the values fit into the setting ranges, as shown above.
Related Parameter
The main function provided by the parameter related to electronic gears is given in the following
table.
10000 (Pn46) × 2
0 (Pn4A)
2000 (Pn4B)
10000 (Pn46) × 2
0 (Pn4A)
1000 (Pn4B)
10000 (Pn46) × 2
0 (Pn4A)
40000 (Pn4B)
2500 (Pn46) × 2
0 (Pn4A)
10000 (Pn4B)
1 (Pn46) × 2
0 (Pn4A)
4 (Pn4B)
or
Parameter
No.
Parameter name Explanation Reference
Pn40
Command Pulse
Multiplying Setting
The command pulses are multiplied by a factor of 2 or 4 when
using 90° phase difference signal inputs is selected as the in-
put format for the command pulses in the Command Pulse
Mode (Pn42).
Page 5-48
