Using the Internal Clock (CS1 CPU Units Only) Section 1-2
1-2 Using the Internal Clock (CS1 CPU Units Only)
The internal clock of the CPU Unit is set to “00 year, 01 month, 01 day (00-01-
01), 00 hours, 00 minutes, 00 seconds (00:00:00), and Sunday (SUN)” when
the Battery Set is mounted in the CS-series CPU Unit.
When using the internal clock, turn ON the power supply after mounting the
Battery Set and 1) use a Programming Device (Programming Console or CX-
Programmer) to set the clock time, 2) execute the CLOCK ADJUSTMENT
(DATE) instruction, or 3) send a FINS command to start the internal clock from
the correct current time and date.
The Programming Console operation used to set the internal clock is shown
below.
Key Sequence
MON
Data
Initial display
↓
↑
SHIFT
WRITE
FUN
0
Specify: Yr Mo Day Hr Min S
CHG
