Omron SYSMAC CS/CJ Series User Manual

333
PLC Comparison Charts Appendix A
Initial
set-
tings
(contd.)
Pro-
gram-
ming
Con-
sole
Programming Con-
sole language
Set on DIP switch CS1: Set on DIP
switch
CS1-H: Set from
Programming
Console
Set on DIP
switch
No Set on DIP
switch
Errors Error Log Area No (Fixed) No (Fixed) No (Fixed:
DM 6001 to
DM6030)
Set in PLC
Setup
No (Fixed:
DM 6569 to
DM 6599)
Not registering user-
defined FAL errors in
error log
CJ1: No
CJ1-H: Yes
CJ1M: Yes
CS1: No
CS1-H: Yes
No No No
Opera-
tion
CPU Standby No No No Set in PLC
Setup
No
Auxil-
iary
Area
Condi-
tion
Flags
ER, CY, <, >, =,
Always ON/OFF
Flag, etc.
Input using symbols,
e.g., ER.
Input using sym-
bols, e.g., ER.
Yes Yes Yes
Clock pulses Input using symbols,
e.g., 0.1 s.
Input using sym-
bols, e.g., 0.1 s.
Yes Yes Yes
Servic-
ing
CPU Service Dis-
able Bit
No No No Yes No
Codes for connected
devices
No No No Yes No
Peripherals process-
ing cycle times
No No No Yes No
CPU Bus Unit ser-
vice interval
No No No Yes No
Peripherals con-
nected to CPU
enabled/disabled
No No No Yes No
Host Link/NT Link
Service Disable Bit
No No No Yes No
Peripheral Service
Disable Bit
No No No Yes No
Scheduled Refresh
Disable Bit
No No No Yes No
Inner Board General
Purpose Monitoring
Area
No Yes Yes No Yes
Cycle time over Yes Yes Yes Yes Yes
Tasks First Task Flag Yes Yes No (Only First
Scan Flag)
No (Only First
Scan Flag)
No (Only First
Scan Flag)
Debug-
ging
Online Editing Dis-
abled Flag
Yes Yes Yes (AR) No No
Online Edit Standby
Flag
Yes Yes Yes (AR) No No
Output OFF Bit Yes Yes Yes Yes Yes
Forced Status Hold
Bit
Yes Yes Yes Yes Yes
File
mem-
ory
File Memory Instruc-
tion Flag
Yes Yes No Yes No
EM File Memory For-
mat Error Flag
Yes (Except for CJ1M
CPU Units)
Yes No No No
EM File Format Start-
ing Bank
Yes (Except for CJ1M
CPU Units)
Yes No No No
Mem-
ory
DIP Switch Status
Flags
Yes (pin 6) Yes (pin 6) Yes (AR, pin 6
only)
No Yes (AR, pin 6)
IOM Hold Bit Yes Yes Yes Yes Yes
Inter-
rupts
Max. subroutine/
action processing
time
Yes Yes Yes No No
Interrupt Task Error
Flag
Yes Yes Yes No No
Item CJ Series CS Series C200HX/HG/
HE
CVM1/CV
Series
CQM1H
