Omron SYSMAC CS/CJ Series User Manual

48
Basic Concepts Section 2-1
• Program the blocks from top to bottom and then from left to right.
0000
00
(a)
0000
01
LD 000000
AND 000001
0010
00
(b)
0010
01
LD 001000
AND 001001
OR LD
0005
00
(c)
OR 000500
0000
02
(a)
AND 000002
AND NOT 000003
0000
03
(c)
0000
06
(f)
OR 000006
0000
04
0000
05
LD 000004
AND 000005
AND LD
0005
00
OUT 000500
(1)
(2)
(3)
(4)
(5)
Address Instruction Operand
000200 LD 000000
000201 AND 000001
000202 LD 001000
000203 AND 001001
000204 OR LD ---
000205 OR 000500
000206 AND 000002
000207 AND NOT 000003
000208 LD 000004
000209 AND 000005
000210 OR 000006
000211 AND LD ---
000212 OUT 000500
(a)
(b)
(c)
(d)
(e)
(f)
(1)
(2)
(3)
(4)
(5)
