Sequence Output Instructions Section 3-2

SINGLE BIT SET

(CS1-H, CJ1-H,

or CJ1M only)

SETB

@SETB

!SETB

532

SETB(532) turns ON the specified bit in the specified word when the execu-

tion condition is ON.

Unlike the SET instruction, SETB(532) can be used to set a bit in a DM or EM

word.

Output

Required

SINGLE BIT

RESET

(CS1-H, CJ1-H,

or CJ1M only)

RSTB

@RSTB

!RSTB

533

RSTB(533) turns OFF the specified bit in the specified word when the execu-

tion condition is ON.

Unlike the RSET instruction, RSTB(533) can be used to reset a bit in a DM or

EM word.

Output

Required

SINGLE BIT

OUTPUT

(CS1-H, CJ1-H,

or CJ1M only)

OUTB

@OUTB

!OUTB

534

OUTB(534) outputs the result (execution condition) of the logical processing

to the specified bit.

Unlike the OUT instruction, OUTB(534) can be used to control a bit in a DM

or EM word.

Output

Required

Instruction

Mnemonic

Code

Symbol/Operand Function Location

Execution

condition

D: Word address

N: Bit number

SETB(532)

D: Word address

N: Bit number

RSTB(533)

D: Word address

N: Bit number

OUTB(534)
