K3T @ Intelligent Signal Processor Protocol Appendix L
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents
(data format)
Data
+0 Number of send data words
(4 digits Hex)
0003 to 0022 (3 to 34 decimal)
+1 Number of compared data
(4 digits Hex)
0001 to 0020 (1 to 32 decimal)
+2 Relevant unit No.
(2 digits BCD)
00 to 99
•
•
•
+ 33 Relevant unit No.
(2 digits BCD)
00 to 99
Offset Contents (data format) Data
+0 Number of receive data
words (4 digits Hex)
0004 to 0061 (4 to 97 decimal)
+1 to +2 Display value
(5 digits Hex)
Relevant unit No.
Number of compared data
+0
+1
+2
+33
Number of send data wordsFirst word of
send data
~ ~
Relevant unit No.(Undefined)
(Undefined)
+0
+1
+2
+3
+94
+95
+96
Display value
Status
Number of receive data wordsReceive data
storage words
~ ~
Display value
(Undefined)
Display value
(Undefined)
Display value
Status
00000 to 99999
Negative sign: F (5th digit in BCD)
Example 12345
+1
+2
2345
0001
Example –1234
+1
+2
1234
000F
