Omron SYSMAC NX series Startup Guide

33
NX-series
Load Cell Input Unit
(NX-RS1201)
Scale (5 kg)
Unit power supply
Personal computer
(Sysmac Studio
already installed)
Ch1 Gross Weight Value/Force Measurement Value DINT
=
10
Display value = 10 kg
10 kg
Measured material
Load cell
From the Sysmac Studio’s I/O map, you can check the values of Ch1 Gross Weight Value/Force
Measurement Value DINT and Ch1 Gross Weight Value/Force Measurement Value REAL. The
following is how to check measurement values from the Sysmac Studio’s I/O map.
