Omron TJ2-MC64 - PROGRAMMING User Manual

Examples and tips
PROGRAMMING MANUAL 275
Revision 1.0
/i
Input signal - Parameter name Parameter
setting
CN1 pin number
Sigma-II Sigma-V
P_OT (active high) - Pn50A.3
N_OT (active high) - Pn50B.0
DEC (active high) - Pn511.0
0 40 (SI0) 13 (SI0)
1 41 (SI1) 7 (SI1)
2 42 (SI2) 8 (SI2)
3 43 (SI3) 9 (SI3)
4 44 (SI4) 10 (SI4)
5 45 (SI5) 11 (SI5)
6 46 (SI6) 12 (SI6)
7Always ON
8Always OFF
/P_OT (active low) - Pn50A.3
/N_OT (active low) - Pn50B.0
/DEC (active low) - Pn511.0
9 40 (SI0) 13 (SI0)
A 41 (SI1) 7 (SI1)
B 42 (SI2) 8 (SI2)
C 43 (SI3) 9 (SI3)
D 44 (SI4) 10 (SI4)
E 45 (SI5) 11 (SI5)
F 46 (SI6) 12 (SI6)
/EXT1 (active low) - Pn511.1
/EXT2 (active low) - Pn511.2
/EXT3 (active low) - Pn511.3
0-3 Always OFF
4 44 (SI4) 10 (SI4)
5 45 (SI5) 11 (SI5)
6 46 (SI6) 12 (SI6)
7Always ON
8, 9-C Always OFF
EXT1 (active high) - Pn511.1
EXT2 (active high) - Pn511.2
EXT3 (active high) - Pn511.3
D 44 (SI4) 10 (SI4)
E 45 (SI5) 11 (SI5)
F 46 (SI6) 12 (SI6)
