No.17S010-01
65/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
Name Description
GainSelector Selects which Gain is controlled by the various Gain features.
Gain Controls the selected gain as an absolute physical value. This is an amplification factor
applied to the video signal.
GainAuto Sets the automatic gain control (AGC) mode. The exact algorithm used to implement
AGC is device-specific.
GainAutoLimitMax Determine the upper limit of gain when GainAuto is set to Continuous.
GainAutoLimitMin Determine the lower limit of gain when GainAuto is set to Continuous.
AutoLightTarget Determine the brightness target for GainAuto.
BlackLevelSelector Selects which Black Level is controlled by the various Black Level features.
BlackLevel Controls the black level as an absolute physical value. This represents a DC offset
applied to the video signal.
BalanceRatioSelector Selects which Balance ratio to control.
BalanceRatio Controls ratio of the selected color component to a reference color component. It is
used for white balancing.
BalanceWhiteAuto Controls the mode for automatic white balancing between the color channels. The
white balancing ratios are automatically adjusted.
Name Description
PixelCorrectionAllEnabled Enable pixel correction for all pixels.
PixelCorrectionIndex Determine index of targeted pixel for pixel correction.
PixelCorrectionEnabled Determine if targeted pixel is enabled for pixel correction.
PixelCorrectionX Determine x-coordinate of targeted pixel for pixel correction.
PixelCorrectionY Determine y-coordinate of targeted pixel for pixel correction.
Name Description
UserSetSelector Selects the feature User Set to load, save or configure.
UserSetLoad Loads the User Set specified by UserSetSelector to the device and makes it active.
UserSetSave
Save the User Set specified by UserSetSelector to the non-volatile memory of the
device.
UserSetDefault
Selects the feature User Set to load and make active by default when the device is
reset.
