No.17S010-01
66/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
Name Description
ChunkModeActive Activates the inclusion of Chunk data in the payload of the image.
ChunkSelector Selects which Chunk to enable or control.
ChunkEnable Enables the inclusion of the selected Chunk data in the payload of the image.
ChunkCounterSelector Selects which counter to retrieve data from.
ChunkCounterValue Returns the value of the selected Chunk counter at the time of the FrameStart event.
ChunkGainSelector Selects which Gain to return.
ChunkGain Returns the gain used to capture the image.
ChunkBlackLevelSelector Selects which Black Level to return.
ChunkBlackLevel Returns the black level used to capture the image included in the payload.
ChunkExposureTimeSelector Selects which exposure time is read by the ChunkExposureTime feature.
ChunkExposureTime Returns the exposure time used to capture the image.
ChunkGamma Returns the gamma used to capture the image.
Name Description
TestPendingAck Tests the device's pending acknowledge feature. When this feature is written, the
device waits a time period corresponding to the value of TestPendingAck before
acknowledging the write.
TestEventGenerate Generates a Test Event.
TriggerEventTest This register is used to control the generation of test events.
Aegis Electronic Group, Inc.
For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com
