Omron V640 Series User Manual

CIDRW System
User’s Manual
SECTION 7
ID Tag Memory Maps
SECTION 7
Appendix
111
ID Tag Memory Maps
The memory maps of the RI-TRP-DR2B(-30) and RI-TRP-WR2B(-30) ID Tags are given below.
• The carrier ID memory area starts from page 1 (fixed).
• 00h to 87h in the table are addresses.
• The RI-TRP-WR2B(-30) has a memory capacity of 136 bytes.
• The RI-TRP-WR2B(-30) has a memory capacity of 8 bytes.
Page 8 bytes/1 page
1 00h 01h 02h 03h 04h 05h 06h 07h
2 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh
3 10h 11h 12h 13h 14h 15h 16h 17h
4 18h 19h 1Ah 1Bh 1Ch 1Dh 1Eh 1Fh
5 20h 21h ••• ••• 27h
6 28h 29h ••• ••• 2Fh
7 30h 31h ••• ••• 37h
8
9 :
10 : :
11 :
12
13
14 68h 69h ••• ••• 6Fh
15 70h 71h ••• ••• 77h
16 78h 79h ••• ••• 7Fh
17 80h 81h ••• ••• 87h
DATASEG LENGTH
Carrier
ID
16
"S01" 8
"S02" 8
"S03" 8
"S04" 8
"S05" 8
"S06" 8
"S07" 8
"S08" 8
"S09" 8
"S10" 8
"S11" 8
"S12" 8
"S13" 8
"S14" 8
"S15" 8
Carrier ID
(16 byte)
Data area
(Total of 120
bytes)
■ RI-TRP-DR2B(-30)
ID Tag Memory Map
Example of data
segment settings
Page 8 bytes/1 page
1 00h 01h 02h 03h 04h 05h 06h 07h
DATASEG LENGTH
Carrier ID 8
Carrier ID
(8 byte)
■ RI-TRP-WR2B(-30)
ID Tag Memory Map
Example of data
segment settings
