SECTION 4
Command/Response Format
CIDRW System
User’s Manual
SECTION 4
Reading from/Writing to ID Tags
■ SAME WRITE
This command writes the same data to multiple pages of an ID Tag. Any page(s) can be specified.
ID Tag Memory Maps Refer to page 111.
The response code (when normal: 00) is returned.
Example: Clearing All Data on Pages 1 and 17 of the Amplifier Unit to 0
Parameter Description
Parameter Description
Page designation Pages are specified by setting the bits corresponding to pages that are to be read to 1 and setting
the other bits to 0, then converting the result to a hexadecimal character string.
Write data Specify the write data.
Response
code
CR
000Dh
Response
code
CR
000Dh
Command
Command code Page designation (8 characters)
Write data
CR
Data 1 ⋅ ⋅ ⋅ Data 8
0300 0DH
Bit 7-07-321076- 1076 -210
Page Sys - Sys Sys - Sys 17 16 15 14 13 - 8 7 6 5 - 1 Sys Sys
Designation 0* 0* 0* 0* 0* 0/1 0/1 0/1 0/1 0/1 ••• 0/1 0/1 0/1 0/1 ••• 0/1 0* 0*
Value 00 00 to 07 00 to FF 00 to FC
* Always specify 0. If you specify 1 an error (Response code: 14) will occur.
Response
Command
00000000000001111111111111111100
Binary
notation
Command
code
Page designation Write data CR
03000007FFFC00000000000000000Dh
Response
