40
SECTION 4
Command/Response Format
CIDRW System
User’s Manual
SECTION 4
Reading from/Writing to ID Tags
■ TEST
Performs a communications test on communications between the host device and Amplifier Unit.
When an Amplifier Unit receives a test command, it sends the response code and command test data
to the host device as the response.
* Number of data n < 136 (2-character units)
The response code (when normal: 00) and the received test data are returned.
Example: Performing a Test for the Amplifier Unit Using the Data 12345678
Command code
Test data
CR
Data 1 ••• Data n
10 0Dh
Parameter Description
Parameter Description
Test data The data to be sent in the test is specified with a hexadecimal value. (270 characters max.)
However, note that odd numbers of characters cannot be used.
Response
code
Test data
CR
Data 1 ••• Data n
00 0Dh
Command code
Test data
CR
Data 1 Data 2 Data 3 Data 4
1 0 123456780Dh
Response
code
Test data
CR
Data 1 Data 2 Data 3 Data 4
00123456780Dh
To Next Page
