25
CIDRW System
User’s Manual
SECTION 2
Connections and Wiring
SECTION 2
Installation and Connections/Wiring
Connections and Wiring
Amplifier Unit
Connector for Connecting a CIDRW Head
1. Align the pin on the connector with the
channel in the cable connector and
insert the cable connector.
Hold the fixed part of the connector while making
this insertion.
2. After inserting the connector fully
home, turn the fixed part clockwise to
lock it.
Disconnecting the CIDRW head.
Please pull it straight out after turn a connector counterclockwise and removing a lock.
If it is difficult to pull the connector out , press down on the Amplifier Unit while pulling on the connector.
Please do not pull a cable forcibly.
