SECTION 3
Communications Test
CIDRW System
User’s Manual
SECTION 3
Preparing for Communications
Communications Test between ID Tags and CIDRW System
Send a command from the host device and check that normal communications with the ID Tag is pos-
sible. Place an ID Tag in the communications area of the CIDRW Head connected to the Amplifier Unit
for which communications is to be tested.
• READ
The data is read from pages 1 and 3 of the Amplifier Unit.
•WRITE
The data is written to pages 8 and 10 of the Amplifier Unit.
If the command ends normally, the contents of the ID Tag will be as follows:
ID Tag contents
Page 1 12h 34h 56h 78h 90h 12h 34h 56h
Page 2
Page 3 11h 22h 33h 44h 55h 66h 77h 88h
Page 4
Response code Page 1 Page 3 CR
0 0 123456789012345611223344556677880Dh
Response code CR
000Dh
Page 8 11h 22h 33h 44h 55h 66h 77h 88h
Page 9
Page 10 01h 23h 45h 67h 89h ABh CDh EFh
Command
00000000000000000000000000010100
Binary notation
Command code Page designation CR
0100000000140Dh
Command
00000000000000000000101000000000
Command code Page designation Data of page 8 Data of page 10 CR
0 2 0 0 00000A0011223344556677880123456789ABCDEF 0Dh
Binary
notation
Response
