SECTION 5
Window Configuration
SECTION 5
Browser Interface
Noise Measurement Window
The Noise Measurement Window allows you to continuously send the NOISE MEASUREMENT com-
mand to the Amplifier Unit and display the results in realtime.
The horizontal axis gives the time and the vertical axis gives the noise level (0 to 99).
Peak noise level
Start/Stop Button
Graph Clear Button
