Omron V680-HS63 - Page 131

RFID System
User's Manual
SECTION 7
Characteristics According to Operating Conditions
SECTION 7
Appendices
129
 V680S-D2KF67
The interrogation zone given here are for reference only. For information on communications ranges, refer to
Communications Range Specifications in this section. The interrogation zone depends on the type of RF Tags used, the
ambient temperature, surrounding metals, and noise. Be sure to check carefully when installing the system.
p.112
40
60
80
20
100
Y
-100 -80 -60 -40 -20 0 20 40 60 80X
40
60
80
20
100
Y
-100 -80 -60 -40 -20 0 20 40 60 80X
Read/Write
V680-HS52䋨Embedded in Non-Metal䋩 and V680S-D2KF67
Read/Write
Read/Write
V680-HS63䋨with Non-Metal on Back Surface䋩 and V680S-D2KF67
V680-HS65䋨with Metal on Back Surface䋩 and V680S-D2KF67
Y
X
Y
X
50
100
150
200
Y
-250 -200 -150 -100 -50 0 50 100 150 200 X
Y
X
