Omron V680-HS63 - Page 134

132
SECTION 7
Characteristics According to Operating Conditions
RFID System
User's Manual
SECTION 7
Appendices
 V680S-D2KF68M
The interrogation zone given here are for reference only. For information on communications ranges, refer to
Communications Range Specifications in this section. The interrogation zone depends on the type of RF Tags used, the
ambient temperature, surrounding metals, and noise. Be sure to check carefully when installing the system.
p.115
40
60
80
20
100
Y
-100 -80 -60 -40 -20 0 20 40 60 80X
50
100
150
200
Y
-250 -200 -150 -100 -50 0 50 100 150 200 X
40
60
80
20
100
Y
-100 -80 -60 -40 -20 0 20 40 60 80X
50
100
150
200
Y
-250 -200 -150 -100 -50 0 50 100 150 200 X
Read/Write
V680-HS63䋨with Metal on Back Surface䋩
and V680S-D2KF68M
Metal on back: Steel (Horizontal-facing RF Tag)
Read/Write
V680-HS63䋨with Metal on Back Surface䋩
and V680S-D2KF68M
Metal on back: Steel (Vertical-facing RF Tag)
Read/Write
V680-HS65䋨with Metal on Back Surface䋩
and V680S-D2KF68M
Metal on back: Steel (Horizontal-facing RF Tag)
Read/Write
V680-HS65䋨with Metal on Back Surface䋩
and V680S-D2KF68M
Metal on back: Steel (Vertical-facing RF Tag)
Y
X
Y
X
Y
X
Y
X
