 V680-HS52-W/R
 General Specifications
Item Model V680-HS52-W
(Standard cable, waterproof connector)
V680-HS52-R
(Flexible cable, non-waterproof connector)
Ambient operating
temperature
10 to 60C (with no icing)
Ambient storage
temperature
25 to 75C (with no icing)
Ambient operating
humidity
35% to 95% (with no condensation)
Insulation resistance 20 M min. (at 500 VDC) between cable terminals and the case
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min between cable terminals and case
Degree of protection IP67 (IEC 60529:2001), Oil resistance equivalent
to IP67G (JIS C 0920:2003, Appendix 1)
(Antenna portion)
See Note 1.
IP67 (IEC 60529:2001), Oil resistance equivalent
to IP67G (JIS C 0920:2003, Appendix 1)
(Antenna portion)
See Note 2.
Vibration resistance 10 to 500 Hz, 1.5-mm double amplitude, acceleration: 100 m/s
2
, 1 sweep in each 3 directions (up/
down, left/right, and forward/backward) for 8 minutes each
Shock resistance 500 m/s
2
, 3 times each in 6 directions (Total: 18 times)
Dimensions M22  65 mm
Material ABS resin, brass, and epoxy resin filler
Weight Approx. 850 g (with 12.5-m cable)
Cable length Standard lengths of 2 and 12.5 m
Note 1. The degree of protection for the Connector is IP67/IP65. Oil resistance has been tested using a specific oil as defined
in the OMRON test method.
2. The Connector is not waterproof. Oil resistance has been tested using a specific oil as defined in the OMRON test
method.
