Section 6 Using Field Extension Mode
Section 6
Functions
155
RFID System
User's Manual
(Modbus TCP)
4. A confirmation message will be displayed. Click the OK Button.
5. Click the Reboot Button. A Confirm Reboot Dialog Box will be displayed. Click the OK Button.
If you turn OFF the power supplies to the Slave Reader/Writers or if a communications error occurs for a Slave Reader/
Writer (e.g., Ethernet Cable disconnection) before you restart the Reader/Writers, an execution status error will occur
and the Reader/Writers will not restart normally. If that occurs, turn OFF the power supplies to all of the Reader/Writers
and then turn them back ON.
6. The following dialog box is displayed after the Reader/Writer has finished rebooting.
Click the OK Button to connect to the Reader/Writer.
Click this button to reboot
the Reader Writer.
Click this button to cancel
rebooting the Reader Writer.
