Omron V680 Series - Page 21

RFID System
User's Manual
(Modbus TCP)
Section 1 Features
Section 1
Product Overview
19
 Easy Operation
A Web server is provided so that you can easily perform setup and status monitoring by connecting to
a computer, without the need for any special software.
You can connect a computer to the Switching Hub to easily set up the Reader/Writers and check the
status of the Reader/Writers.
Switching Hub
PLC
Personal computer
Reader/Writer
24-VDC
power supply
