Omron V680 Series User Manual

RFID System
User's Manual
(Modbus TCP)
Section 1 Product Specifications
Section 1
Product Overview
41
 V680-D1KP58HTN
 General Specifications
 Dimensions
V680-D1KP58HTN
The RF Tag can be placed in the Attachment in either direction. The direction does not affect operation.
Item Model V680-D1KP58HTN
Compliance standards ISO/IEC 18000-3 (15693)
Memory capacity 1,000 bytes (user area)
Memory type EEPROM
Data retention 10 years after writing (85°C or less), 0.5 years after writing (85 to 125°C)
Total data retention at high temperatures exceeding 125°C is 10 hours
See Note 1
Write endurance 100,000 writes for each block (25°C)
Ambient operating
temperature
-25 to 85°C (with no icing)
Ambient operating
humidity
No restrictions.
Ambient storage
temperature
-40 to 250°C (with no icing)
(Data retention: -40 to 125°C)
Ambient storage
humidity
No restrictions.
Degree of protection IP67 (IEC 60529:2001)
Oil resistance equivalent to IP67G (JIS C 0920:2003, Appendix 1)
See Note 2
Vibration resistance No abnormality after application of 10 to 2,000 Hz, 1.5-mm double amplitude, acceleration: 150 m/s
2
,
10 sweeps each in X, Y, and Z directions for 15 minutes each
Shock resistance No abnormality after application of 500 m/s
2
, 3 times each in X, Y, and Z directions (Total: 18 times)
Dimensions 80 dia. × 10 mm
Materials PPS resin
Weight Approx. 70 g
Note1. After storing RF Tags at high temperatures, rewrite the data even if changes are not required. High temperatures are
those between 125 and 250°C.
2. Oil resistance has been tested using a specific oil as defined in the OMRON test method.
(60 dia.)
80 dia.
14 dia.
10±0.2
7.51.25
(1.25)
(5°)
(5°)
18 dia.
Two, 1-mm corners
(Unit: mm)
Case material PPS resin
