RFID System
User's Manual
(Modbus TCP)
Section 2 System Configuration
Section 2
System Configuration
61
About the Ethernet communication abnormality
If an Ethernet network is configured into a loop as shown below, broadcast packets are accumulated in the band, and
the communication is disabled. Therefore, do not configure the Ethernet network into a loop.
When a large amount of broadcast packets or multicast packets flow into the Ethernet network, Reader/Writers may
stop its operation. Please do not send a large amount of packet. Please separate the Reader/Writers from the network
segment that broadcast or multicast packets flow.
Sending broadcast storm
Reader/Writer
HUB
HUB
HUB
Broadcast storm
Communication disabled
To Next Page
