76
Section 4 Installation
RFID System
User's Manual
(Modbus TCP)
Section 4
Installation and Connections
V680S-A64
Either use the V680S-A64 Attachment to mount the Connector Cover with screws or permanently
attach the RF Tags with adhesive.
1. Through a cord into a connector cover.
2. Press a connector cover up until it clicks.
3.
Install it together with the RFID reader/writer and V680S-A64.
Tightening torque: 1.2 N·m
M4 screw
Spring washer
Flat washer
To Next Page
