Section 4 Installation
Section 4
Installation and Connections
RFID System
User's Manual
(Modbus TCP)
77
V680S-A66
Either use the V680S-A66 Attachment to mount the Connector Cover with screws or permanently
attach the RF Tags with adhesive.
1. Through a cord into a connector cover.
2. Press a connector cover up until it clicks.
3.
Install it together with the RFID reader/writer and
V680S-A66.
Tightening torque: 1.2 N·m
M4 screw
Spring washer
Flat washer
