D-100 Dual Network Interface Installation Guide 03/18 - 1015-2 / 35094 Page 26
Register
Address
Description Register Type Read/Write Comment
41047 Volume Total Mode 1 –Gal Floating point register (1 of 2) Read Only
41048 Volume Total Mode 1 –Gal Floating point register (2 of 2) Read Only
41049 Volume Total Mode 2 –Gal Floating point register (1 of 2) Read Only
41050 Volume Total Mode 2 –Gal Floating point register (2 of 2) Read Only
41051 Volume Total Mode 1 – Liters Floating point register (1 of 2) Read Only
41052 Volume Total Mode 1 – Liters Floating point register (2 of 2) Read Only
41053 Volume Total Mode 2 – Liters Floating point register (1 of 2) Read Only
41054 Volume Total Mode 2 – Liters Floating point register (2 of 2) Read Only
41055 Volume Total Mode 1 – M³ Floating point register (1 of 2) Read Only
41056 Volume Total Mode 1 – M³ Floating point register (2 of 2) Read Only
41057 Volume Total Mode 2 – M³ Floating point register (1 of 2) Read Only
41058 Volume Total Mode 2 – M³ Floating point register (2 of 2) Read Only
41079 Volume Total Mode 1 – Ft³ Floating point register (1 of 2) Read Only
41080 Volume Total Mode 1 – Ft³ Floating point register (2 of 2) Read Only
41081 Volume Total Mode 2 – Ft³ Floating point register (1 of 2) Read Only
41082 Volume Total Mode 2 – Ft³ Floating point register (2 of 2) Read Only
41059 Mass Total –Lbs Floating point register (1 of 2) Read Only
Mass units are only
available when using
F-2000 Vortex Meter.
41060 Mass Total –Lbs Floating point register (2 of 2) Read Only
41061 Mass Total –kg Floating point register (1 of 2) Read Only
41062 Mass Total –kg Floating point register (2 of 2) Read Only
41063 Auxiliary Input Total (Di3) Floating point register (1 of 2) Read Only
41064 Auxiliary Input Total (Di3) Floating point register (2 of 2) Read Only
41066 Zero (+) Mode 1 Volume Total 0 – 1 0 – 1
Not
applicable
Read/Write
Write a value of 1 to
registers to reset totals.
Re-write a value of zero
to the register once the
totals reset.
41068 Zero (-) Mode 2 Volume Total 0 – 1 0 – 1
Not
applicable
Read/Write
41069 Zero Auxiliary Input Total (Di3) 0 – 1 0 – 1
Not
applicable
Read/Write
41070 Reserved for future use
