D-100 Dual Network Interface Installation Guide 03/18 - 1015-2 / 35094 Page 28
Register
Address
Description
Register
Range
Data
Range
Over
Range
Read/Write Comment
40042 Volume Total Mode 1 - kGal 0 – 65535 0 – 999 Read Only Low Order
40043 Volume Total Mode 1 - MGal 0 – 65535 0 – 999 Read Only Middle Order
40044 Volume Total Mode 1 – GGal 0 – 65535 0 – 65534 65535 Read Only High Order
40045 Volume Total Mode 2 – kGal 0 – 65535 0 – 999 Read Only Low Order
40046 Volume Total Mode 2 – MGal 0 – 65535 0 – 999 Read Only Middle Order
40047 Volume Total Mode 2 – GGal 0 – 65535 0 – 65534 65535 Read Only High Order
40048 Volume Total Mode 1 – kLiters 0 – 65535 0 – 999 Read Only Low Order
40049 Volume Total Mode 1
– MLiters 0 – 65535 0 – 999 Read Only Middle Order
40050 Volume Total Mode 1 – GLiters 0 – 65535 0 – 65534 65535 Read Only High Order
40051 Volume Total Mode 2 – kLiters 0 – 65535 0 – 999 Read Only Low Order
40052 Volume Total Mode 2
– MLiters 0 – 65535 0 – 999 Read Only Middle Order
40053 Volume Total Mode 2 – GLiters 0 – 65535 0 – 65534 65535 Read Only High Order
40054 Volume Total Mode 1 –M³ 0 – 65535 0 – 999 Read Only Low Order
40055 Volume Total Mode 1 – kM³ 0 – 65535 0 – 65534 65535 Read Only High Order
40056 Volume Total Mode 2 –M³ 0 – 65535 0 – 999 Read Only Low Order
40057 Volume Total Mode 2 – kM³ 0 – 65535 0 – 65534 65535 Read Only High Order
40058 Mass Total – kLbs 0 – 65535 0 – 999 Read Only
Mass units are only
available when using
F-2200 Vortex Meter.
40059 Mass Total – MLbs 0 – 65535 0 – 65534 65535 Read Only
40060 Mass Total – Kkgs 0 – 65535 0 – 999 Read Only
40061 Mass Total – Mkgs 0 – 65535 0 – 65534 65535 Read Only
40062 Auxiliary Input Total (Di3) 0 – 65535 0 – 999 Read Only Low Order
40063 Auxiliary Input Total (x1000) 0 – 65535 0 – 65534 65535 Read Only High Order
40065 Zero (+) Mode 1 Volume Total 0 – 1 0 – 1
Not
applicable
Read/Write
Write a value of 1 to
registers to reset totals.
Re-write a value of zero
to registers once the
totals reset.
40067 Zero (-) Mode 2 Volume Total 0 – 1 0 – 1
Not
applicable
Read/Write
40068 Zero Auxiliary Input Total (Di3) 0 – 1 0 – 1
Not
applicable
Read/Write
