6.4 ANALOG INPUT(S)
Property Default Value Read-only or
Writable
Comment
Object Identier Analog-input, 1 to analog-input,10 Read-only
Object Name Various Read-only
Object Type Analog-input Read-only
Present Value REAL Writable
Description Analog-input, # Name Read-only
Status Flags (F,F,F,F) Read-only
Event State Normal Read-only
Reliability No-fault-detected Read-only
Out-of-Service FALSE Writable
Update interval 100 Read-only
Units Various Read-only
Min-Present-Value -1000000000 Read-only
Max-Present-Value 1000000000 Read-only
Resolution 0.000001 Read-only
Analog Input Objects
Object Identier Function
Analog Input 1 Energy rate
(Not used)
Analog Input 2 Volume rate
Analog Input 3 Supply internal
temperature
Analog Input 4 Return temperature
(Not used)
Analog Input 5 Delta temperature
(Not used)
Analog Input 6 Signal strength
Analog Input 7 Signal quality
Analog Input 8 Speed of sound
Analog Input 9 Peak energy rate
(Not used)
Analog Input 10 Average delta temp
(Not used)
BACnet Engineering Units for Analog Inputs (Defaults)
Energy rate: Not available
Volume rate: gpm, l/s, ft3/m or m3/h
Temperature: °F or °C
Signal strength: No units (0 - 100 counts)
Signal quality: No units (3 - 31 counts, 3 = best)
Speed of sound: ft/s or m/s
