Onicon F-4600 Series User Manual

11451 Belcher Road South, Largo, FL 33773 • USA • Tel +1 (727) 447-6140 • Fax +1 (727) 442-5699 • sales@onicon.com
F-4600 With LCD Flow Meter Manual 06/18 - 2020-3 / 35874 Page 25
6.5 ANALOG VALUE(S)
Property Default Value Read-only or
Writable
Comment
Object Identier Analog-value, 1 to analog-value,22 Read-only
Object Name Various Read-only
Object Type Analog-value Read-only
Present Value REAL Writable
Description Analog-value, # Name Read-only
Status Flags (F,F,F,F) Read-only
Event State Normal Read-only
Reliability No-fault-detected Read-only
Out-of-Service FALSE Writable
Units Various Read-only
Priority Array {NULL, NULL, NULL, NULL, NULL,
NULL, NULL, NULL, NULL, NULL,
NULL, NULL, NULL, NULL, NULL,
NULL}
Read-only
Relinquish Default 0 Read-only
Analog Value Objects
Object Identier Single Mode Function Dual Mode Function
Analog Value 1 (Not used) Energy total Mode 1 energy total
Analog Value 2 (Not used) Energy total Mode 2 energy total
Analog Value 3 (Not used) Y-T-D energy total Y-T-D mode 1 energy total
Analog Value 4 (Not used) Y-T-D energy total Y-T-D mode 2 energy total
Analog Value 5 (Not used) Previous year energy total Previous year mode 1 energy total
Analog Value 6 (Not used) Previous year energy total Previous year mode 2 energy total
Analog Value 7 (Not used) User dened energy total User mode 1 energy total
Analog Value 8 (Not used) User dened energy total User mode 2 energy total
Analog Value 9 Volume total Mode 1 volume total
Analog Value 10 Volume total Mode 2 volume total
Analog Value 11 Y-T-D volume total Y-T-D mode 1 volume total
Analog Value 12 Y-T-D volume total Y-T-D mode 2 volume total
Analog Value 13 User dened volume total User mode 1 volume total
Analog Value 14 User dened volume total User mode 2 volume total
Analog Value 15 Aux pulse input 1 total Aux pulse input 1 total
Analog Value 16 Aux pulse input 2 total Aux pulse input 2 total
Analog Value 17 Aux pulse input 3 total Aux pulse input 3 total
Analog Value 18 Run hours Run hours
Analog Value 19 (Not used) Incremental energy total Incremental energy total mode 1
Analog Value 20 (Not used) Incremental energy total Incremental energy total mode 2
