SECTION 1.0: INTRODUCTION
1.1 PURPOSE OF THIS GUIDE
The purpose of this guide is to provide installation and commissioning procedures, and basic
operating and servicing instructions for the ONICON F-4600 ow meter with optional LCD
display.
1.3 STANDARD FEATURES AND SPECIFICATIONS
• Detachable enclosure with alphanumeric display and user interface
• Three 2-wire signal ports can be congured as pulse input or outputs. One of the ports can
be congured as an analog output.
!
WARNING
Only qualied service personnel should attempt to install or service this product. Serious injury
may result from the improper installation or use of this product.
1.2 TYPICAL F-4600 FLOW METER
The F-4600 inline ow meter utilizes direct path wetted ultrasonic transducers for measuring
the volumetric ow and temperature of liquids in a wide variety of applications. The meter is
provided with a detachable enclosure with a built-in user interface/display.
POWER
24 V AC/DC
Input Power
Input and Output
Signals and
BACnet / MODBUS

Onicon F-4600 Series Specifications

General

Brand	Onicon
Model	F-4600 Series
Category	Measuring Instruments
Language	English
